Grinding Wheel Fused Alumina Zirconia F220 High Strength

Grinding Wheel Fused Alumina Zirconia F220 High Strength
Grinding Wheel Fused Alumina Zirconia F220 High Strength Grinding Wheel Fused Alumina Zirconia F220 High Strength Grinding Wheel Fused Alumina Zirconia F220 High Strength

Large Image :  Grinding Wheel Fused Alumina Zirconia F220 High Strength

Product Details:
Place of Origin: CHINA
Brand Name: EASTKING
Certification: SGS/ISO
Model Number: ZA
Payment & Shipping Terms:
Minimum Order Quantity: 20MT
Price: USD3000-3300/MT
Packaging Details: 1MT/bag, 1.25MT/bag, 25kg bag into 1MT big bag, on pallet
Delivery Time: 7days for the quantity within 500MT
Payment Terms: T/T, L/C, D/A, D/P, , MoneyGram
Supply Ability: 1000MT/Month
Contact Now

Grinding Wheel Fused Alumina Zirconia F220 High Strength

Description
Product Name: Zirconia Fused Alumina Color: Grey
Application: Grinding Wheel Shape: Grains
Grits: F4-F220 Sample: Free Of Charge
High Light:

Grinding Wheel Fused Alumina Zirconia

,

F220 Fused Alumina Zirconia

,

Grey Fused Alumina Zirconia

High Grade Abrasives Material Fused Alumina Zirconia ZA 40% for Grinding Wheels



Product Description

Zirconia fused alumina is produced by putting rich aluminum, zirconium materials and additives in electic furances, smelting with high temperature above 2000°C, cooling down with special technology, and compacting with Barmac plastic, which has the characteristics of tenacious texture, dense structure and high strength.



Zirconia Alumina F20 F22 F24

PRODUCT NAME
Fused Alumina Zirconia
RAW MATERIAL
ALUMINUM OXIE AND ZIRCONIUM OXIDE
STANDARD
FEPA JIS
GRADE
Al2O3
ZrO2
TiO2
Fe2O3
SiO2
ZA25%
68-72
24-30
≤1.5
≤0.5
≤1.0
ZA40%
55-57
35-44
≤1.5
≤0.5
≤1.0



AVAILABLE SIZES
0-0.5MM 0.5-1MM 1-1.5MM 1.5-2MM 2.5-3MM 3-3.5MM 3.5-4MM 0-1MM 1-2MM 2-3MM 1-3MM 3-5MM 4-5MM 3-6MM 5-8MM
F4 F5 F6 F7 F8 F10 F12 F14 F16 F20 F22 F24 F30 F36 F46 F54 F60 F70 F80 F90 F100 F120 F150 F180 F220
JIS#4 JIS#5 JIS#6 JIS#7 JIS#8 JIS#10 JIS#12 JIS#14 JIS#16 JIS#20 JIS#24 JIS#30 JIS#36 JIS#46 JIS#54 JIS#60 JIS#70 JIS#80 JIS#90 JIS#100 JIS#120 JIS#150 JIS#180 JIS#220
Physical Properties
Crystal Form
Monoclinic,tetragonal system
Reaction with carbon
Forming carbide since 1650℃
Color
Grey
True Density
4.20g/cm3
Bulk Density
2.18g/cm3
Moh's hardness
9.0
Melting point
1900℃
Knoop hardness
1450-2000kg/cm2
Maximum service temperature
1700℃
Specific heat capacity(cal/g.℃)
0.2205(50-500℃)
Heat conductivity
0.2718 cal/cm2.sec.℃
Linear expansivity(X10-6)
6.82(100-700℃)
Applications
Making zircon fused alumina brick and building materials.
Used for making bonded abrasives products,and process of grinding,sandblasting,surface treatment of metal products and other materials.
With good melt erosion resistance,Zirconia fused alumina has good grinding effect on steel,iron casting,heat resistant steel and other alloy materials.
Zirconia fused alumina can be made for heavy duty Zirconia fused alumina grinding wheel,snagging,cutting disc,Fiber disc,grinding rails,high speed abrasive belts etc.
Used for making coated abrasives products.
Used for making lapping paste,polishing wax,emery cloth,sandpaper etc.

Grinding Wheel Fused Alumina Zirconia F220 High Strength 0Grinding Wheel Fused Alumina Zirconia F220 High Strength 1
