Product Details:
|
| Product Name: | Chrome Coated White Aluminum Oxide 99.31% | Application: | Resin Cutting Disc |
|---|---|---|---|
| Al2O3 Content: | 99.34% | Color: | Green |
| Usage: | Resin Disc Wheels | Shape: | Grains |
| High Light: | Fused Aluminium Oxide Granules,99.34% Aluminium Oxide Granules,Chrome Coated Fused Aluminium Oxide |
||
Chrome Coated White Fused Aluminum Oxide WFA99% for Ceramic Cutting Wheels
1. White Fused Alumina Descriptions
Coated white fused alumina is made of high-qality white fused alumina as the raw material and plate iron oxide or other material on the surface of abrasive during high temperature treatment. White fused alumina is a highly pure form of aluminium oxide which is suitable for use with stainless steel and aluminium. This iron-free, reusable blasting medium is angular, brittle and hard. It has a powerful abrasive effect on the surface being blasted. White fused alumina belongs to the group of fused alumina.
2. White Fused Alumina Characteristics
Strong hydrophilicity
Uniform particle size
Strong bonding force
Good heating dissipation performance
High grinding efficiency
Specific gravity: approx. 4.0 g/cm3
Bulk density: approx. 1.5 – 2.1 g/cm3
3. White Fused Alumina Packing
1). 25 kg/bag, in bulk;
2). 25 kg/bag, 40 bags/big bag;
3). 25 kg/ bag, 40 bags/pallet;
4). According to customer's requirement
4. White Fused Alumina Applications
Resin bonded abrasives
Blasting, surface Treatment, Rust Removal
Cosmetics products manufacturing, Beauty crafts and Dermabrasion etc.
Ceramic products such as ceramic filter plate, ceramic membrane etc.
Grinding wheels, Cutting off Wheels, sandbelt, sandpaper etc.
5. White Fused Alumina Specifications
| Particle Size | Specific Gravity | Chemical Composition (%) | ||||
| Al2O3 | SiO2 | Fe2O3 | TiO2 | Na2O | ||
| #240 ~ #1200 | ≥ 3.85 | ≥ 90.0 | ≤ 5.00 | ≤ 0.80 | ≤ 5.00 | - |
| #1500 ~ #4000 | ≥ 3.76 | ≥ 80.0 | ≤ 18.00 | ≤ 1.00 | ≤ 3.00 | - |
| Particle Size | Particle Distribution (µm) | |||
| Maximum Particle Size | Particle Size at d03 | Particle Size at d50 | Particle Size at d94 | |
| # 240 | ≤ 127 | ≤ 103 | 58.6 ± 3.0 | ≥ 40.0 |
| # 280 | ≤ 112 | ≤ 87.0 | 49.4 ± 3.0 | ≥ 33.0 |
| # 320 | ≤ 98.0 | ≤ 74.0 | 41.1 ± 2.5 | ≥ 27.0 |
| # 360 | ≤ 86.0 | ≤ 66.0 | 36.1 ± 2.0 | ≥ 23.0 |
| # 400 | ≤ 75.0 | ≤ 58.0 | 30.9 ± 2.0 | ≥ 20.0 |
| # 500 | ≤ 63.0 | ≤ 50.0 | 26.4 ± 2.0 | ≥ 16.0 |
| # 600 | ≤ 53.0 | ≤ 43.0 | 21.1 ± 1.5 | ≥ 13.0 |
| # 700 | ≤ 45.0 | ≤ 37.0 | 17.9 ± 1.3 | ≥ 11.0 |
| # 800 | ≤ 38.0 | ≤ 31.0 | 14.7 ± 1.0 | ≥ 9.00 |
| # 1000 | ≤ 32.0 | ≤ 27.0 | 11.9 ± 1.0 | ≥ 7.00 |
| # 1200 | ≤ 27.0 | ≤ 23.0 | 9.90 ± 0.80 | ≥ 5.50 |
| # 1500 | ≤ 23.0 | ≤ 20.0 | 8.40 ± 0.60 | ≥ 4.50 |
| # 2000 | ≤ 19.0 | ≤ 17.0 | 6.90 ± 0.60 | ≥ 4.00 |
| # 2500 | ≤ 16.0 | ≤ 14.0 | 5.60 ± 0.50 | ≥ 3.00 |
| # 3000 | ≤ 13.0 | ≤ 11.0 | 4.00 ± 0.50 | ≥ 2.00 |
| # 4000 | ≤ 11.0 | ≤ 8.00 | 3.00 ± 0.40 | ≥ 1.30 |
| # 6000 | ≤ 8.00 | ≤ 5.00 | 2.00 ± 0.40 | ≥ 0.80 |
| # 8000 | ≤ 6.00 | ≤ 3.50 | 1.20 ± 0.30 | ≥ 0.60(1) |
| # 10000 | 0.50~0.70 | |||
| # 20000 | 0.40~0.50 | |||
| # 30000 | 0.30~0.39 | |||
