Product Details:
|
Al2O3 Content: | BFA 95.25% | SiO2 Content: | 0.86% |
---|---|---|---|
Bulk Density: | 1.71-1.89g/cm3 | Sample: | Freely |
Type: | Sand Disc | Feature: | Long Time Materials |
High Light: | Barmac Crushed Brown Fused Alumina,95% Brown Fused Alumina,High hardness Fused Alumina |
Barmac Crushed Brown Fused Alumina BFA F24# Corundum For High Grade Resin Bonded Grinding Abrasives
Brown Fused Alumina 95% Introduction
Brown Fused Alumina is made from bauxite and coke (anthracite) , through melting at high temperature in electric- arc furnace. The range of general granularity size is F4 ~ F320, its chemical composition varies depending on the size of the particle.
Brown Fused Alumina Characteristics
High hardness, high crystallinity, good linear flow performance, weak adherence, no explosion while using, no cracking, no pulverizing, abrasive product with dark blue color after burning, no net cracks, no rust.
Brown Fused Alumina Properties
Items | Unit | Index | Typical | |
Chemical Composition | Al2O3 | % | 95%min | 95.56 |
SiO2 | % | 1.2max | 0.96 | |
Fe2O3 | % | 0.30max | 0.09 | |
TiO2 | % | 3.00max | 2.55 | |
Melting point | ℃ | 2050 | ||
Refractoriness | ℃ | 1980 | ||
True density | g/cm3 | 3.90min | ||
Mohs hardness | --- | 9.00min | ||
Refractory grain sizes | mm | 0-50, 0-1, 1-3, 3-5, 5-8 | ||
Fine powder | mesh | -80, 100, 150, 200, 325F | ||
Abrasives Grits | FEPA | 8, 14, 16, 20, 22,24, 30, 36, 40, 46, 60, 70, 80, 90, 100, 120, 150, 180, 220, 240 | ||
Fixed Furnace Barmac Crushing |
||||
Items | Unit | Index | Typical | |
Chemical Composition | Al2O3 | % | 95%min | 95.23 |
SiO2 | % | 1.5max | 1.28 | |
Fe2O3 | % | 0.30max | 0.17 | |
TiO2 | % | 3.00max | 2.62 | |
Melting point | ℃ | 2050 | ||
Refractoriness | ℃ | 1980 | ||
True density | g/cm3 | 3.90min | ||
Mohs hardness | --- | 9.00min | ||
Refractory grain sizes | mm | 0-50, 0-1, 1-3, 3-5, 5-8 | ||
Fine powder | mesh | -80, 100, 150, 200, 325F | ||
Abrasives Grits | FEPA | 8, 14, 16, 20, 22,24, 30, 36, 40, 46, 60, 70, 80, 90, 100, 120, 150, 180, 220, 240 |
Brown Fused Alumina Applications
Abrasive: Produce ceramic grind wheel, resinoid grinding wheel, Grinding stone, Grinding block, sand paper, sand cloth, sand belt, polish wax, abrasive paste, coating etc..
Refractory material: Mainly used for abrasion and high temperature resistant, inoxidizable aggregate and filling of shaped and monolithic refractory in steel metallurgy, various industrial stoves, electric furnace etc..
Sandblasting abrasive: Mainly used for various material workpieces to decontaminate, derusting, prevent corrosion, remove oxide skin etc.
Grit |
Bulk density (g/cm3) |
Grit |
Bulk density (g/cm3) |
---|---|---|---|
F12 | 1.84-1.98 | F54 | 1.69-1.83 |
F14 | 1.84-1.98 | F60 | 1.66-1.80 |
F16 | 1.83-1.97 | F70 | 1.66-1.80 |
F20 | 1.81-1.95 | F80 | 1.62-1.76 |
F22 | 1.80-1.94 | F90 | 1.60-1.74 |
F24 | 1.80-1.94 | F100 | 1.57-1.71 |
F30 | 1.78-1.92 | F120 | 1.54-1.68 |
F36 | 1.76-1.90 | F150 | 1.52-1.66 |
F40 | 1.73-1.87 | F180 | 1.50-1.64 |
F46 | 1.71-1.85 | F220 | 1.48-1.62 |
Brown Fused Alumina Packing
1). 25 kg/bag, in bulk;
2). 25 kg/bag, 40 bags/big bag;
3). 25 kg/ bag, 40 bags/pallet;
4).According to customer's requirement
