Product Details:
|
Color: | White | Shape: | Grains Or Fine Powder |
---|---|---|---|
Refractoriness: | 1770min. | Application: | Foundry |
Al2O3 Content: | 42-48% | SiO2 Content: | 50-52% |
CaO Content: | 0.19% | ||
High Light: | 1770min. Refractoriness Refractory Sand,Fully calcined Refractory Sand,1770min. foundry casting sand |
Good Performance Foundry Mullite Sand and Powder for Precision Casting Investment
1. Mullite Sand Introduction
Mullite sand, produced through high temperature calcined process, is a kind of high quality casting sand made from of high quality Kaolin mines. The main crystalline phase is mullite. It has good performance on lower thermal expansion rate, uniform expansion, better anti vibration, good hardness etc.
It is generally used in stainless steel precision casting process. When the refractory degree is about 1750 degrees, the higher the aluminum content in mulberry sand is, the lower the iron content is. The smaller the dust is, the better the quality of mullite product is.
2. Mullite Sand Specifications
Item/ Grade | Specifications | |||
E-45 | E-44 | E-43 | E-42 | |
Al2O3 % | 45-48 | 44-46 | 43-45 | 42-45 |
Fe2O3 % | 0.8-1.2 | 1.2-1.5 | 1.5-2.0 | 2.0-3.0 |
SiO2 % | 49-52 | 50-53 | 50-53 | 51-54 |
Ti02 % | 0.8 | 0.9 | 1.0 | 1.2 |
K2O+Na2O % | 0.3 | 0.4 | 0.4 | 0.5 |
CaO+MgO % | 0.5 | 0.5 | 0.6 | 0.7 |
Bulk density g/cm3(min) | 2.55 | 2.53 | 2.50 | 2.46 |
Refractoriness °C (min) | 1770 | 1760 | 1740 | 1720 |
Mullte Phase% (min) | 65 | 60 | 55 | 45 |
3. Mullite Sand General advantages
Ø Easy out of shell.
Ø No deformation.
Ø No reduced scale.
Ø Good brightness, Good finish.
Ø Product rate is high.
3. Mullite Sand Characteristics
Ø High refractoriness.
Ø Aluminum content high, the iron content low.
Ø High volume density.
Ø Thermal expansion coefficients of small.
Ø Physicochemical stability.
Ø Fully calcined
Ø Dust content low
Ø The specification standards.
4. Mullite Sand Particle sizes Available
Ø Size of sand: 8-16,16-30,30-60,30-80,60-80,80-120 (mesh):Used for investment casting.
Ø Size of powder: -200mesh,-270mesh,-325mesh: Used for investment casting and refractories.
Ø Size of particle: 0-1mm,1-3mm,3-5mm,5-8mm,8-15mm,0-5mm,0-50mm:Used for refractories.
5. Mullite Sand Applications
Ø Product is suitable for Stainless steel, alloy steel, carbon steel, heat-resistant steel, titanium alloy, nickel alloy, aluminum alloy, cast iron, cast copper complex precision castings and big, medium and small castings, etc.
Ø Product is suitable for precision casting ,Silicon Sol investment casting, lost wax casting ,Cast steel, cast copper, Vacuum casting, plaster filler v-process, casting coatings, casting mold shell, etc.
