Product Details:
|
Product Name: | Abrasive Sea Garnet | Garnet Content: | 95.3% |
---|---|---|---|
Mesh: | Customerized | Usage: | Water Jet Cutting Of Stone |
Melting Point: | 1300 | B. D.: | 1.70-2.16g.cm3 |
High Light: | 95.3% Sea Garnet Sand,2.16g/cm3 Sea Garnet Sand,Garnet Abrasive Media |
Sea Garnet Sand Abrasives Sand Garnet Sand for Water Jet Cutting of Metal, Stone and Glass
1. Garnet Introduction
Garnet sand for water jet cutting is a non-metallic naturally obtainable mineral abrasive belonging to the silicate family. As Almandine garnet, it is the heaviest and hardest of garnets. Due to suitable hardness, physical and chemical properties, it's used widely for water jet cutting, Sandblasting, water filtration. With its crystalline shape giving a fast cutting action and longer life span, Garnet is a kind of ideal, environment-friendly and efficient natural abrasive.
2. Garnet Specifications
CHEMICAL COMPOSITION | TYPICAL PHYSICAL PROPERTIES | ||
SiO2 | 34-38% | Uniformity Coefficient | 1.33 |
Iron(Fe2O3 +FeO) | 25-33% | Hardness: | Mohs:7.5-8.0 |
AL2O3 | 17-22% | Melting Point: | Sublimes at 1300 ℃ |
CaO | 1-9% | Specific Gravity: | 3.8-4.1 g/cm3 |
MgO | 4-6% | Bulk density(LPD): | 1.8-2.1 g/cm3 |
MnO | 0-1% | Shape | Sub Angular |
Na2O | 0-1% | Chloride | <25ppm |
TIO2 | 0-1% | Acid Solubility(HCL) | <1% |
3. Garnet General advantages
Garnet abrasives are cost effective, have low dust levels and are safe to use.
Safe to Use: Containing less than 0.5% free silica, Garnet meets the most stringent industry and military specifications with total chlorides of typically 15-20 ppm.
4. Garnet Characteristics
Color | Type | Mohs Hardness | Production Process | Applications | Available Sizes |
Dark brown color garnet sand | Rock sand. | 8.0 | Crushing and washing process. | Sandblasting, rust removal, Water filtration, etc. | 8-14#,10-20#,16-20#,20-40#,30-60#,80# |
Brown color garnet sand (Red) | Rock sand | 7.5-8.0 | Crushing and washing process. We wash rock sand up to 6 times. So it’s of high purity. | Sandblasting, rust removal with low conductivity, water filtration, etc. | 8-14#,10-20#,16-20#,20-40#,30-60#,80#,120# |
Pink color garnet sand (light) | River sand | 7.5-8.0 | alluvial garnet sand was scouring and washing by river water. It is Cleaner and with less sharp edges than rock sand. | Sandblasting, water jet cutting with less blocking in nozzles. | 10-20#,20-40#,30-60#,80# |
Pink-red color garnet sand | Sea sand, | 8.0 | It is alluvial garnet sand. The sand source was formed by the ancient rock near the sea. So it’s very clean and with high purity. | Especially for water jet cutting without blocking in nozzles. | 60#,80# |
5. Garnet Applications
1) Sand blasting
Garnet abrasive’s hardness is moderate and have high bulk density. It have free silica and good toughness .It is the ideal "environmentally friendly" sand blasting materials
2) Free grinding
The Grinding grade garnet abrasive is applied to the picture tube, optical glass, monocrystalline silicon, lenses, watches and clocks, glass, crystal glass, jade and other fields of free grinding. It is widely used in domestic advanced abrasive materials.
3) Resin grinder
Garnet abrasive with the right color, good hardness, toughness, and be suitable for the type of particle cross-section and blade retention. It can be used as a substitute for 20%-30% filler corundum resin grinding tool.
4) Coated abrasives
Garnet abrasive are materials production of paper, gauze and other manufacturers of raw materials production
5)Filter media
Filter media Is a new application field of garnet, the underlying medium using granular garnet filtrating bed, can clean drinking water and waste water. It is a new type of filter material , especially suitable for non-ferrous metal processing, oil drilling mud weighting agent.
6)Water jet cutting
Based on garnet abrasive cutting medium, rely on high pressure water jet cutting in basic and apply in oil (gas) cutting pipe, steel etc. It is a new type, environmental protection, safe way to cut.
7)Filter media
Filter media Is a new application field of garnet, the underlying medium using granular garnet filtrating bed, can clean drinking water and waste water. It is a new type of filter material , especially suitable for non-ferrous metal processing, oil drilling mud weighting agent.
