Product Details:
|
| Product Name: | Abrasive Garnet Sand | Garnet Content: | 95.6% |
|---|---|---|---|
| Mesh: | Customerized | Usage: | Water Jet Cutting Of Glass |
| Melting Point: | 1300 | B. D.: | 1.70-2.16g.cm3 |
| High Light: | Garnet Abrasive Grit,High Purity Garnet 120 Mesh,95.6% Garnet 120 Mesh |
||
30/60/80 mesh Used for Sandblasting and Water Jet Cutting Garnet Abrasive Grit
1. Garnet Introduction
Garnet is one of the very best abrasive options for many blast shop operations. Some of the benefits are listed below. High Speed, very Low Dust and the lowest Consumption rate compared to conventional abrasives highlight the advantageous of Garnet. Some of the other benefits are listed below.
Extremely hard (8 MOH Hardness) blast abrasive
Very low dust generation
Recyclable up to 5 times
Used for Dry Blasting, Slurry Blasting, and predominately the predominate media for Waterjet
Available in grit sizes of including 80 & 30x60 to #120 (2-4 mil profile)
Lower consumption rates as compared to conventional abrasives
By recycling and lowering lbs/sq.ft. consumed, greatly reduces abrasive cost and waste
< .5% Free Silica
2. Garnet Specifications
| CHEMICAL COMPOSITION | TYPICAL PHYSICAL PROPERTIES | ||
| SiO2 | 34-38% | Uniformity Coefficient | 1.33 |
| Iron(Fe2O3 +FeO) | 25-33% | Hardness: | Mohs:7.5-8.0 |
| AL2O3 | 17-22% | Melting Point: | Sublimes at 1300 ℃ |
| CaO | 1-9% | Specific Gravity: | 3.8-4.1 g/cm3 |
| MgO | 4-6% | Bulk density(LPD): | 1.8-2.1 g/cm3 |
| MnO | 0-1% | Shape | Sub Angular |
| Na2O | 0-1% | Chloride | <25ppm |
| TIO2 | 0-1% | Acid Solubility(HCL) | <1% |
3. Garnet General advantages
Garnet abrasives are cost effective, have low dust levels and are safe to use.
1). angular sharp, efficient
2). economical abrasive
3). pollution-free production process
4). high purity,low impurity, multiple gravity separation and magnetic separation
5). Poisonless and tasteless without radioactivity
6). environmental health, free of free silicon
4. Garnet Characteristics
| Color | Type | Mohs Hardness | Production Process | Applications | Available Sizes |
| Dark brown color garnet sand | Rock sand. | 8.0 | Crushing and washing process. | Sandblasting, rust removal, Water filtration, etc. | 8-14#,10-20#,16-20#,20-40#,30-60#,80# |
| Brown color garnet sand (Red) | Rock sand | 7.5-8.0 | Crushing and washing process. We wash rock sand up to 6 times. So it’s of high purity. | Sandblasting, rust removal with low conductivity, water filtration, etc. | 8-14#,10-20#,16-20#,20-40#,30-60#,80#,120# |
| Pink color garnet sand (light) | River sand | 7.5-8.0 | alluvial garnet sand was scouring and washing by river water. It is Cleaner and with less sharp edges than rock sand. | Sandblasting, water jet cutting with less blocking in nozzles. | 10-20#,20-40#,30-60#,80# |
| Pink-red color garnet sand | Sea sand, | 8.0 | It is alluvial garnet sand. The sand source was formed by the ancient rock near the sea. So it’s very clean and with high purity. | Especially for water jet cutting without blocking in nozzles. | 60#,80# |
5. Garnet Applications
Applications:
1. Q: Why do we choose the products of your company?
A: Because our company is the global leading waterjet almandine rock garnet abrasive factory, producing high quality rock almandine water jet garnet abrasives. We have the rich rutile and garnet resources.
2. Q: Can your company provide some sample for test?
A:We are glad to provide the sample for test before the order. But please send us your requirements about the product.
3. Q: What is the standard of your company's products and how much of your annual output value?
A:The standard is GB/T 8337-2012 and we can produce 200000 tons yearly.
4. Q: What kind of products do you offer?
A: Garnet sand 20-30mesh,30-40mesh,40-60mesh,60-100 mesh and 100-120mesh.
5. Q: what payment do you accept?
A: We accept T/T, L/C at sight or others. Usually it within 5-7 days from payment received.
