Product Details:
|
| Product Name: | Abrasive Garnet Sand 8/12 | Garnet Content: | 95.5% |
|---|---|---|---|
| Usage: | Blasting Media | B. D.: | 1.70-2.16g.cm3 |
| Mesh: | 8/12 Mesh | Feature: | Top Grade |
| High Light: | 80 Mesh Garnet Abrasive Sand,95.5% Garnet Abrasive Sand,Garnet Blasting Media |
||
Sandblating Abrasive Blasting Media Alluvial Garnet Mesh 8/12 18/35 20/40 80/100 Garnet Sand
1. Garnet Introduction
Garnet is one of the very best abrasive options for many blast shop operations. Some of the benefits are listed below. High Speed, very Low Dust and the lowest Consumption rate compared to conventional abrasives highlight the advantageous of Garnet.
2. Garnet Specifications
| Product Name | Garnet 18/35 Mesh for Sandblasting | ||
| Colour | Red | Hardness | 7-8 Mohs |
| Fracture | Sharp | Specific Weight | 3.9g/cm³ |
| SiO2 | 41.64 | Melting Point | 1300℃ |
| Fe2O3 | 3.05 | Al2O3 | 18.77 |
| CaO | 4.48 | MnO | 0.42 |
| Na2O | 0.30 | FeO | 21.62 |
| TiO2 | 0.58 | K2O | 0.19 |
| P2O5 | 0.074 | LOI | -1.52 |
| MgO | 7.22 | Chloride | 10-15ppm(25ppm max) |
3. Garnet General advantages
Garnet abrasives are cost effective, have low dust levels and are safe to use.
1). angular sharp, efficient
2). economical abrasive
3). pollution-free production process
4). high purity,low impurity, multiple gravity separation and magnetic separation
5). Poisonless and tasteless without radioactivity
6). environmental health, free of free silicon
4. Garnet Characteristics
| Color | Type | Mohs Hardness | Production Process | Applications | Available Sizes |
| Dark brown color garnet sand | Rock sand. | 8.0 | Crushing and washing process. | Sandblasting, rust removal, Water filtration, etc. | 8-14#,10-20#,16-20#,20-40#,30-60#,80# |
| Brown color garnet sand (Red) | Rock sand | 7.5-8.0 | Crushing and washing process. We wash rock sand up to 6 times. So it’s of high purity. | Sandblasting, rust removal with low conductivity, water filtration, etc. | 8-14#,10-20#,16-20#,20-40#,30-60#,80#,120# |
| Pink color garnet sand (light) | River sand | 7.5-8.0 | alluvial garnet sand was scouring and washing by river water. It is Cleaner and with less sharp edges than rock sand. | Sandblasting, water jet cutting with less blocking in nozzles. | 10-20#,20-40#,30-60#,80# |
| Pink-red color garnet sand | Sea sand, | 8.0 | It is alluvial garnet sand. The sand source was formed by the ancient rock near the sea. So it’s very clean and with high purity. | Especially for water jet cutting without blocking in nozzles. | 60#,80# |
5. Garnet Applications
Applications:
