Product Details:
|
| Bulk Density: | 2.55-2.75g/cm3 | Refractoriness: | 1793min. |
|---|---|---|---|
| Al2O3 Content: | 43-45% | SiO2 Content: | 50.5-52.5 |
| Packaging Details: | 25 Kgs In Plastic Bag, 40 Bags/Pallet | Material: | Mullite Or Kaolin |
| High Light: | Refractory Sand 60 Mesh,Petroleum Industry Mullite Sand,Petroleum Industry Refractory Sand |
||
Foundry Mullite Sand Precision Refractory Sand 30/60 Mesh For Metallurgy/Petroleum Industry
1. Mullite Sand Introduction
The chemical components of mullite are all chemical substances with strong fire resistance, and their properties are relatively stable. It mainly includes: alumina, silica, etc., the content of alumina is between 42% and 46%, and the content of silica is between 51-53%. The best raw ore make our foundry sands can keep relatively stable below 1750℃.
2. Mullite Sand Specifications
| Item/ Grade | Specifications | |||
| E-45 | E-44 | E-43 | E-42 | |
| Al2O3 % | 45-48 | 44-46 | 43-45 | 42-45 |
| Fe2O3 % | 0.8-1.2 | 1.2-1.5 | 1.5-2.0 | 2.0-3.0 |
| SiO2 % | 49-52 | 50-53 | 50-53 | 51-54 |
| Ti02 % | 0.8 | 0.9 | 1.0 | 1.2 |
| K2O+Na2O % | 0.3 | 0.4 | 0.4 | 0.5 |
| CaO+MgO % | 0.5 | 0.5 | 0.6 | 0.7 |
| Bulk density g/cm3(min) | 2.55 | 2.53 | 2.50 | 2.46 |
| Refractoriness °C (min) | 1770 | 1760 | 1740 | 1720 |
| Mullte Phase% (min) | 65 | 60 | 55 | 45 |
3. Mullite Sand General advantages
Ø Easy out of shell.
Ø No deformation and No reduced scale.
Ø Good brightness and Good finish.
3. Mullite Sand Characteristics
Ø High refractoriness.
Ø Aluminum content high, the iron content low.
Ø High volume density.
Ø Thermal expansion coefficients of small.
Ø Physicochemical stability.
Ø Fully calcined and Dust content low
Ø The specification standards.
4. Mullite Sand Particle sizes Available
Ø Size of sand: 8-16,16-30,30-60,30-80,60-80,80-120 (mesh):Used for investment casting.
Ø Size of powder: -200mesh,-270mesh,-325mesh: Used for investment casting and refractories.
Ø Size of particle: 0-1mm,1-3mm,3-5mm,5-8mm,8-15mm,0-5mm,0-50mm:Used for refractories.
5. Mullite Sand Applications
The foundry sands are mainly used in precision investment casting,especially in reinforcement layer, gypsum filling V method molding and vacuum suction casting, as well as refractories for large, medium and small steel castings, widely used in machinery, aviation, weapons, metallurgy, petroleum and other industries.
The grain size of foundry sand is also different for different purposes. Generally, we use "mesh" to measure the grain size of mullite, including 8 to 16 mesh, 16 to 30 mesh, 30 to 60 mesh, 60 to 80 mesh, 80 to 120 mesh; mullite powder mainly includes 200 mesh and 300 mesh.
