Product Details:
|
| Product Name: | Black Silicon Carbide 98.58% | Fe2O3: | 0.13% |
|---|---|---|---|
| Application: | Semiconductor Electronics Devices | Bulk Density: | 1.45-1.56g/cm3 |
| Shape: | Powder | Color: | Gray |
| High Light: | 98.58% Silicon Carbide Powder,98.58% Black Silicon Carbide,Super Micro Black Silicon Carbide |
||
Super Micro Powder Black Silicon Carbide SiC 98.5% For Semiconductor Electronics Devices
1. Black Silicon Carbide Introduction
Silicon carbide is made of quartz sand, stone tar (or coal), wood chips and other raw materials in the resistance by high temperature smelting, silicon and carbon bonds made of ceramic compounds. Silicon carbide exists in nature in the form of rare minerals such as mozanite. Since 1893, silicon carbide powder has been used extensively as abrasive. The sintered silicon carbide powder can provide hard ceramic-like silicon carbide particles and can be used in materials such as automotive brake pads, clutches and ballistic vests that require high durability, such as light-emitting diodes, early radio detectors Classes are also used in the manufacture of electronic devices. Silicon carbide is now widely used in the manufacture of high temperature, high voltage semiconductors. By lely method to grow large pieces of silicon carbide single crystal. The gemstone of artificial mulberry is obtained by cutting the bulk silicon carbide single crystal prepared by the Lely method.
2. Black Silicon Carbide Chemical Composition (%)
| Grit | Sic | F.C. | Fe2O3 |
| F12-F90 | ≥98.50 | <0.20 | ≤0.60 |
| F100-F150 | ≥98.00 | <0.30 | ≤0.80 |
| F180-F220 | ≥97.00 | <0.30 | ≤1.20 |
| F230-F400 | ≥96.00 | <0.40 | ≤1.20 |
| F500-F800 | ≥95.00 | <0.40 | ≤1.20 |
| F1000-F1200 | ≥93.00 | <0.50 | ≤1.20 |
| P12-P90 | ≥98.50 | <0.20 | ≤0.60 |
| P100-P150 | ≥98.00 | <0.30 | ≤0.80 |
| P180-P220 | ≥97.00 | <0.30 | ≤1.20 |
| P230-P500 | ≥96.00 | <0.40 | ≤1.20 |
| P600-P1500 | ≥95.00 | <0.40 | ≤1.20 |
| P2000-P2500 | ≥93.00 | <0.50 | ≤1.20 |
3. Black Silicon Carbide Physical Index
| Grits | Bulk Density g/cm3 |
High Density g/cm3 |
Grits | Bulk Density g/cm3 |
High Density g/cm3 |
| F16 ~ F24 | 1.42~1.50 | ≥1.50 | F100 | 1.36~1.45 | ≥1.45 |
| F30 ~ F40 | 1.42~1.50 | ≥1.50 | F120 | 1.34~1.43 | ≥1.43 |
| F46 ~ F54 | 1.43~1.51 | ≥1.51 | F150 | 1.32~1.41 | ≥1.41 |
| F60 ~ F70 | 1.40~1.48 | ≥1.48 | F180 | 1.31~1.40 | ≥1.40 |
| F80 | 1.38~1.46 | ≥1.46 | F220 | 1.31~1.40 | ≥1.40 |
| F90 | 1.38~1.45 | ≥1.45 |
4. Black Silicon Carbide Size Available
F12-F1200, P12-P2500
0-1mm, 1-3mm, 6/10, 10/18, 200mesh, 325mesh
Other special specifications could be supplied on request.
5. Black Silicon Carbide Applications
F12-F14,use for sandblasting,rust removal,snagging,heavy duty grinding of steel ingot,leather,salt,floor boards.
F14-F30,use for casting play burr,cutting billet and steel tube,flat kibbling,steel ingot grinding,marble grinding,or as refractory material.
F30-F60,use for surface abrasion,outside&surface grinding,centerless grinding,tool grinding of quenching or no-quenching steel profiles,copper or other hard metal.
F60-F100,use for precision grinding, cutter sharpening,gear grinding,etc.
F100-F240,use for cutter sharpening,rough grinding,precision grinding,thread grinding.
F280-F600,use for precision grinding&thread grinding of instrument and matter an gear products.
F600-F2000,super-precision polishing,mirror polishing,surface lapping,etc.
6. Black Silicon Carbide acking
1. 25kg woven bag, 40 woven bags/jumbo bag.
2. 25kg woven bag, 40 woven bags/pallet
3. 25kg paper bag, 40 paper bags/pallet
4. 25kg paper bag, 40 paper bags/paper box
