Product Details:
|
| Product Name: | Black Silicon Carbide | SiC Content: | 98% |
|---|---|---|---|
| F. C.: | 0.3%max | Fe2O3: | 0.2%max |
| Color: | Black | Application: | Polishing |
| High Light: | SGS Black Silicon Carbide,98% Black Silicon Carbide,SiC High Purity Silicon Carbide |
||
High Purity Black Silicon Carbide SiC 98% for Abrasive Polishing and Sandblasting
Black Silicon Carbide Introduction
Black silicon carbide is produced at high temperature in an electric resistance type furnace with quarts sand and petroleum coke as its main raw materials. It is used for making bonded and coated abrasive tools, grinding metal and non-metal materials of lower tensile strength, such as gray cast iron yellow bronze, aluminum, stone, leather, rubber, etc.
Black Silicon Carbide Chemical Composition (%)
| Grit | Sic | F.C. | Fe2O3 |
| F12-F90 | ≥98.50 | <0.20 | ≤0.60 |
| F100-F150 | ≥98.00 | <0.30 | ≤0.80 |
| F180-F220 | ≥97.00 | <0.30 | ≤1.20 |
| F230-F400 | ≥96.00 | <0.40 | ≤1.20 |
| F500-F800 | ≥95.00 | <0.40 | ≤1.20 |
| F1000-F1200 | ≥93.00 | <0.50 | ≤1.20 |
| P12-P90 | ≥98.50 | <0.20 | ≤0.60 |
| P100-P150 | ≥98.00 | <0.30 | ≤0.80 |
| P180-P220 | ≥97.00 | <0.30 | ≤1.20 |
| P230-P500 | ≥96.00 | <0.40 | ≤1.20 |
| P600-P1500 | ≥95.00 | <0.40 | ≤1.20 |
| P2000-P2500 | ≥93.00 | <0.50 | ≤1.20 |
Black Silicon Carbide Physical Index
| Grits | Bulk Density g/cm3 |
High Density g/cm3 |
Grits | Bulk Density g/cm3 |
High Density g/cm3 |
| F16 ~ F24 | 1.42~1.50 | ≥1.50 | F100 | 1.36~1.45 | ≥1.45 |
| F30 ~ F40 | 1.42~1.50 | ≥1.50 | F120 | 1.34~1.43 | ≥1.43 |
| F46 ~ F54 | 1.43~1.51 | ≥1.51 | F150 | 1.32~1.41 | ≥1.41 |
| F60 ~ F70 | 1.40~1.48 | ≥1.48 | F180 | 1.31~1.40 | ≥1.40 |
| F80 | 1.38~1.46 | ≥1.46 | F220 | 1.31~1.40 | ≥1.40 |
| F90 | 1.38~1.45 | ≥1.45 |
Black Silicon Carbide Size Available
F12-F1200, P12-P2500
0-1mm, 1-3mm, 6/10, 10/18, 200mesh, 325mesh
Other special specifications could be supplied on request.
Black Silicon Carbide Applications
Black Silicon Carbide acking
1. 25kg woven bag, 40 woven bags/jumbo bag.
2. 25kg woven bag, 40 woven bags/pallet
3. 25kg paper bag, 40 paper bags/pallet
4. 25kg paper bag, 40 paper bags/paper box
